Outdoor displays – wall screens

Outdoor displays are characterized by high brightness and excellent resistance to adverse weather conditions. The modules used can display clear images even in direct sunlight, and the ultra-black color of masks, combined with the small size of LEDs, offers excellent contrast.

Our outdoor displays can be installed almost anywhere. We offer LED displays with a rear and front maintenance system.

Selected versions of the displays can be joined at external corners to cover the corners of building facades for unusual visual effects.

Steel cabinets and aluminum-magnesium cabinets can be used as display housing. The outdoor displays can be mounted on facades (also directly attached to walls without an understructure), and as free-standing devices.

The format, method of assembly, or size can be tailored to the individual needs of our clients.

PREMIUM inexLED solutions

PREMIUM inexLED solutions

inexLED P2.5 outdoor
Pixel pitch (mm)
2,5
LED type
SMD
WModule size (mm)
320x160
RModule resolution
128x64
Number of pixels per 1m²
160.000
Brightness (cd/m²)
3500
Scan mode
1/16
Refresh rate (Hz)
3840
Optimal viewing distance (m)
2,5
Viewing angles (horizontal/vertical)
140/130
Average energy consumption (W/m²)
215
inexLED P3 outdoor
Pixel pitch (mm)
3
LED type
SMD
WModule size (mm)
320x160
RModule resolution
104x52
Number of pixels per 1m²
105.625
Brightness (cd/m²)
3500
Scan mode
1/16
Refresh rate (Hz)
3840
Optimal viewing distance (m)
3
Viewing angles (horizontal/vertical)
140/130
Average energy consumption (W/m²)
250
inexLED P4 outdoor
Pixel pitch (mm)
4
LED type
SMD
WModule size (mm)
320x160
RModule resolution
80x40
Number of pixels per 1m²
62.500
Brightness (cd/m²)
5500
Scan mode
1/10
Refresh rate (Hz)
1920/3840
Optimal viewing distance (m)
4
Viewing angles (horizontal/vertical)
140/130
Average energy consumption (W/m²)
280
inexLED P5 outdoor
Pixel pitch (mm)
5
LED type
SMD
WModule size (mm)
320x160
RModule resolution
64x32
Number of pixels per 1m²
40.000
Brightness (cd/m²)
5500
Scan mode
1/8
Refresh rate (Hz)
1920/3840
Optimal viewing distance (m)
5
Viewing angles (horizontal/vertical)
140/130
Average energy consumption (W/m²)
255
inexLED P6.6 outdoor
Pixel pitch (mm)
6,6
LED type
SMD
WModule size (mm)
320x160
RModule resolution
48x24
Number of pixels per 1m²
22.500
Brightness (cd/m²)
5500
Scan mode
1/6
Refresh rate (Hz)
1920/3840
Optimal viewing distance (m)
6
Viewing angles (horizontal/vertical)
140/130
Average energy consumption (W/m²)
275
inexLED P8 outdoor
Pixel pitch (mm)
8
LED type
SMD
WModule size (mm)
320x160
RModule resolution
40x20
Number of pixels per 1m²
15.625
Brightness (cd/m²)
5500
Scan mode
1/5
Refresh rate (Hz)
1920/3840
Optimal viewing distance (m)
8
Viewing angles (horizontal/vertical)
140/130
Average energy consumption (W/m²)
262

Energy efficiency

Energy consumption of the display was successfully reduced by over 50% with the use of state-of-the-art SMD LEDs and energy-saving control systems.

Highest quality

InexLED-T displays are produced of the highest quality components to make the displayed images uniform and legible.

Ease of service

Only a small part (a single module) of the display can be replaced in case of failure thanks to the modular design of the LED display.
